Keysight E3643A Bench Power Supply
Request a quote
Keysight E3643A benchtop DC power supply with 50W output, dual-range flexibility (0-35V/1.4A or 0-60V/0.8A), low noise <500µVrms, and remote control via GPIB/RS232.
Product details
| Model | E3643A |
| Manufacturer | Keysight |
| Category | DC Power Supplies |
| Availability | Made to order |
Description
Overview
The Keysight E3643A is a 50W benchtop DC power supply combining higher power and higher voltage capabilities. It features dual-range output flexibility, allowing selection between voltage range 1 (0-35V/1.4A) or voltage range 2 (0-60V/0.8A). The instrument provides low noise output, precise regulation, and intuitive control via a vacuum fluorescent display.
Key Features
- 50W maximum power output
- Dual-range outputs: 0-35V/1.4A or 0-60V/0.8A
- Ultra-low ripple and noise: less than 500 µVrms
- Superior load regulation: less than 0.01%
- Meter accuracy better than 0.05%
- Store and recall up to five operating states
- Remote control via RS232 and GPIB interfaces
- Vacuum fluorescent display for clear visibility
Applications
- High-power high-voltage circuit testing
- Production line testing and quality assurance
- Automated test equipment via GPIB interface
- Research and development applications
Specifications
| Maximum Voltage | 60V |
| Maximum Current | 1.5A |
| Maximum Power | 80W |
| Channel/Port Count | 1 |
| Phases | 1 |
| Voltage Range Selector | 50-99.9 |
| Output Voltage | 60 V |
| Current Range Selector | 0-2.49 |
| Output Current | 1.4 A |
| Power Range Selector | 1-199 |
| Power Rating | 50 W |
| Mounting Type | Bench Top |
| Input Voltage | 115 VAC |
| Series | E3640 Series |
| Display | VFD |
| Interface | GPIB,RS-232 |
| Number of Outputs | Single Output |
| Programmable | Yes |
| Special Features | Remote Sense |
