Keysight E3642A Bench Power Supply
Request a quote
Keysight E3642A benchtop DC power supply with 50W output, dual-range flexibility (0-8V/5A or 0-20V/2.5A), low noise <500µVrms, and remote control via GPIB/RS232.
Product details
| Model | E3642A |
| Manufacturer | Keysight |
| Category | DC Power Supplies |
| Availability | Made to order |
Description
Overview
The Keysight E3642A is a 50W benchtop DC power supply offering increased power capability compared to the E3640A series. It features dual-range output flexibility, allowing selection between low-voltage high-current mode (0-8V/5A) or high-voltage low-current mode (0-20V/2.5A). The instrument provides low noise output, precise regulation, and intuitive control via a vacuum fluorescent display.
Key Features
- 50W maximum power output
- Dual-range outputs: 0-8V/5A or 0-20V/2.5A
- Ultra-low ripple and noise: less than 500 µVrms
- Superior load regulation: less than 0.01%
- Meter accuracy better than 0.05%
- Store and recall up to five operating states
- Remote control via RS232 and GPIB interfaces
- Vacuum fluorescent display for clear visibility
Applications
- High-power component and circuit testing
- Production line testing and burn-in applications
- Automated test equipment via GPIB interface
- Research and development applications
Specifications
| Maximum Voltage | 8V |
| Maximum Current | 5A |
| Maximum Power | 50W |
| Channel/Port Count | 1 |
| Voltage Range Selector | 20-29.9 |
| Output Voltage | 20 V |
| Current Range Selector | 5-9.9 |
| Output Current | 5 A |
| Power Range Selector | 1-199 |
| Power Rating | 50 W |
| Mounting Type | Bench Top |
| Input Voltage | 115 VAC |
| Series | E3640 Series |
| Display | VFD |
| Interface | GPIB,RS-232 |
| Number of Outputs | Single Output |
| Programmable | Yes |
| Special Features | Remote Sense |
