Keysight E3633A 200W DC Power Supply
Request a quote
Keysight E3633A is a 200W dual-range DC power supply with 8V/20A or 20V/10A outputs, ideal for high-current R&D and production testing with GPIB/RS-232 control.
Product details
| Model | E3633A |
| Manufacturer | Keysight |
| Category | DC Power Supplies |
| Availability | Made to order |
Description
Overview
The Keysight E3633A is a 200W single-output DC power supply with dual-range capability, optimized for high-current applications in R&D and production testing. The dual-range design enables users to select between lower voltage with higher current capacity or higher voltage with moderate current, providing flexibility for diverse testing requirements.
Key Features
- Dual-range single output: 8V/20A or 20V/10A
- 200W power capacity
- Low output ripple and noise (350 µVrms or less)
- Four-wire remote sense for accurate load voltage regulation
- Programming accuracy: 0.05% + 10 mV (voltage)
- Save and recall functions for test configurations
- Built-in GPIB and RS-232 remote interfaces
- Overvoltage and overcurrent protection
- Compact benchtop design
Applications
- High-current R&D design verification and prototyping
- Production testing with automated control via GPIB/RS-232
- QA verification for power-intensive circuits
- Laboratory testing of motor drives and power electronics
Specifications
| Maximum Voltage | 20V |
| Maximum Current | 10A |
| Maximum Power | 200W |
| Channel/Port Count | 1 |
