GW Instek PSW 800-4.32 DC Power Supply
Request a quote
GW Instek PSW 800-4.32 programmable DC power supply with 0–800V/4.32A output, 1080W maximum power, CV/CC priority for DUT protection, and series/parallel capability.
Product details
| Model | PSW 800-4.32 |
| Manufacturer | GW Instek |
| Category | DC Power Supplies |
| Availability | Made to order |
Description
Overview
The GW Instek PSW 800-4.32 is a programmable DC power supply with 0–800V/4.32A output and 1080W maximum power. It features multi-range voltage and current configurations ideal for battery testing, LED characterization, and industrial applications. Supports series (up to 2 units) or parallel (up to 3 units) operation.
Key Features
- Output: 0–800V at 0–4.32A (1080W max)
- Multi-range voltage and current combinations
- CV/CC Priority Mode for DUT protection
- Adjustable Slew Rate
- Over-Voltage and Over-Current Protection
- Series/Parallel Operation Capability
- Standard Interfaces: LAN, USB, Analog Control
- LabVIEW Driver and Data Logging Software
- Two-Year Warranty
Applications
- Battery charging and testing
- LED testing and I–V curve verification
- Electronic device power testing
- Industrial power applications
Included Accessories
- User's Manual (printed and CD)
- Power Cord
- PSW-004 Basic Accessories Kit
Specifications
| Voltage Range Selector | 500-999 |
| Output Voltage | 800 V |
| Current Range Selector | 2.5-4.9 |
| Output Current | 4.32 A |
| Power Range Selector | 1-199 |
| Power Rating | 1.08 W |
| Mounting Type | Bench Top |
| Input Voltage | 265 VAC |
| Series | PSW Series |
| Display | Digital |
| Interface | USB,LAN |
| Number of Outputs | Single Output |
| Programmable | Yes |
| Special Features | Multi Ranging, Switching |
