GW Instek PSW 800-1.44 DC Power Supply
Request a quote
GW Instek PSW 800-1.44 programmable DC power supply with 0–800V/1.44A output, 360W maximum power, CV/CC priority for DUT protection, and adjustable slew rate.
Product details
| Model | PSW 800-1.44 |
| Manufacturer | GW Instek |
| Category | DC Power Supplies |
| Availability | Made to order |
Description
Overview
The GW Instek PSW 800-1.44 is a programmable DC power supply with 0–800V/1.44A output and 360W maximum power. It features multi-range voltage and current configurations ideal for battery testing, LED characterization, and industrial applications. Supports series (up to 2 units) or parallel (up to 3 units) operation.
Key Features
- Output: 0–800V at 0–1.44A (360W max)
- Multi-range voltage and current combinations
- CV/CC Priority Mode for DUT protection
- Adjustable Slew Rate
- Over-Voltage and Over-Current Protection
- Series/Parallel Operation Capability
- Standard Interfaces: LAN, USB, Analog Control
- LabVIEW Driver and Data Logging Software
- Two-Year Warranty
Applications
- Battery charging and testing
- LED testing and I–V curve verification
- Electronic device power testing
- Industrial power applications
Included Accessories
- User's Manual (printed and CD)
- Power Cord
- PSW-004 Basic Accessories Kit
Specifications
| Voltage Range Selector | 500-999 |
| Output Voltage | 800 V |
| Current Range Selector | 0-2.49 |
| Output Current | 1.44 A |
| Power Range Selector | 200-499 |
| Power Rating | 360 W |
| Mounting Type | Bench Top |
| Input Voltage | 265 VAC |
| Series | PSW Series |
| Display | Digital |
| Interface | USB,LAN |
| Number of Outputs | Single Output |
| Programmable | Yes |
| Rack Space | 1U |
| Special Features | Multi Ranging, Switching |
