GW Instek PSW-720L25 DC Power Supply, Dual Channel

Overview

The GW Instek PSW-720L25 is a dual-channel programmable switching DC power supply from the PSW-Multi Series. With a maximum output power of 720W, it delivers flexible voltage combinations of 40V/160V and features advanced control modes designed to protect sensitive components during testing and manufacturing.

Key Features

• Dual-channel design with maximum 720W output power
• 40V/160V voltage combinations for diverse testing requirements
• CC/CV priority mode selection for optimal protection during power-on transients
• Adjustable slew rate for controlled voltage and current rise/fall times
• Over-voltage protection (OVP) and over-current protection (OCP) with user-defined thresholds
• Standard LAN and USB Host/Device interfaces
• Optional GPIB-USB and RS232-USB connectivity
• Advanced web server for remote SCPI command execution
• LabVIEW driver and data logging software support
• Analog control and monitoring connector on rear panel

Applications

• LED and battery characterization with inrush current protection
• Capacitive and current-intensive load testing
• Manufacturing test sequences for lighting and power devices
• I-V curve verification with smooth voltage transitions
• Automated test sequences via USB flash drive storage
