GW Instek PSW 250-4.5 Programmable Switching DC Power Supply
GW Instek PSW 250-4.5 programmable DC power supply with 250V/4.5A output, 360W max power, multi-range capability, CV/CC priority, and series/parallel operation support.
Product details
| Model | PSW 250-4.5 |
| Manufacturer | GW Instek |
| Category | DC Power Supplies |
| Availability | Made to order |
Description
Overview
The GW Instek PSW 250-4.5 is a single-output, multi-range programmable switching DC power supply from the PSW-Series family. With rated output of 250V and 4.5A (360W), it provides flexible voltage and current combinations within its power envelope. The unit is particularly suited for battery and LED testing applications, featuring CV/CC priority mode to protect sensitive devices from inrush currents and damage.
The supply supports both series operation (up to 2 units for higher voltage) and parallel operation (up to 3 units for higher current), enabling flexible configuration for various test requirements. Standard interfaces include LAN, USB Host/Device, and analog control, with optional GPIB-USB and RS232-USB connectivity for remote control and monitoring.
Key Features
- Rated Output: 250V, 4.5A, 360W maximum power
- Multi-range voltage and current combinations within rated power envelope
- CV/CC Priority mode for inrush current protection and device safety
- Adjustable slew rate for smooth voltage and current transitions
- Overvoltage Protection (OVP) and Overcurrent Protection (OCP) at 110% default
- Series operation capability for increased voltage
- Parallel operation capability for increased current
- Standard interfaces: LAN, USB Host/Device, analog control connector
- Optional interfaces: GPIB-USB adapter, RS232-USB cable
- LabView driver and data logging software support
- Compact 1/3 rack mount design (EIA/JIS standard)
Applications
- Battery testing and characterization
- LED I-V curve verification and measurement
- Component and circuit testing
- Manufacturing test and quality assurance
- Device protection verification and burn-in
- Power system simulation and verification
Included Accessories
- CD-ROM User Manual and Programmable User Manual
- Region-dependent power cords
- GTL-240 USB Cable (L-type)
- 1042-SWHV0301 Output terminal cover for 250V/800V models
- PSW-008 Basic Accessory Kit for 250V/800V models
- 39BT-50900401 High voltage output terminal
Specifications
| Voltage Range Selector | 200-299 |
| Output Voltage | 250 V |
| Current Range Selector | 2.5-4.9 |
| Output Current | 4.5 A |
| Power Range Selector | 200-499 |
| Power Rating | 360 W |
| Mounting Type | Bench Top |
| Input Voltage | 265 VAC |
| Series | PSW Series |
| Display | Digital |
| Interface | USB,LAN |
| Number of Outputs | Single Output |
| Programmable | Yes |
| Special Features | Multi Ranging, Switching |
| Type | Single Output DC Power Supply |
| Warranty | 2 Years |
Request a quote
