GW Instek PSW-1080L555 DC Power Supply

Overview

The GW Instek PSW-1080L555 is a triple-channel programmable switching DC power supply from the PSW-Multi Series. With a maximum output of 1080W across three channels all configured at 160V, it provides balanced high-voltage capability for testing and power applications. The power supply incorporates advanced CV/CC priority mode selection to protect devices under test from inrush current damage and includes over-voltage (OVP) and over-current (OCP) protection.

Key Features

• Triple-channel output with maximum 1080W; inter-channel latency less than 0.1ms
• Voltage configuration: 160V, 160V, and 160V (uniform across all channels)
• CV/CC priority mode selection for effective DUT protection during power-on transients
• Adjustable slew rate for controlled voltage and current rise/fall times
• Programmable OVP and OCP with default set at 110% of rated values
• Advanced web server with SCPI command support for remote control
• Data logging with 1-second intervals and sequence editing
• Standard interfaces: LAN, USB Host/Device, analog remote control terminal
• Optional interfaces: GPIB-USB adapter, RS232-USB cable
• LabVIEW driver and PC software support

Applications

• High-voltage device testing and characterization
• LED I-V curve measurement at elevated voltages
• Battery charging and discharging at higher voltage levels
• Power electronics and converter testing
• Manufacturing and quality assurance testing
