GW Instek PSW-1080L455 DC Power Supply

Overview

The GW Instek PSW-1080L455 is a triple-channel programmable switching DC power supply from the PSW-Multi Series. With a maximum output of 1080W distributed across three channels with 80V, 160V, and 160V configurations, it is designed for diverse testing and power applications. The power supply features advanced CV/CC priority mode selection to protect devices under test from inrush current damage and includes over-voltage (OVP) and over-current (OCP) protection capabilities.

Key Features

• Triple-channel output with maximum 1080W; inter-channel latency less than 0.1ms
• Voltage configuration: 80V, 160V, and 160V
• CV/CC priority mode selection for effective DUT protection during power-on transients
• Adjustable slew rate for controlled voltage and current rise/fall times
• Programmable OVP and OCP with default set at 110% of rated values
• Advanced web server with SCPI command support for remote control
• Data logging with 1-second intervals and sequence editing
• Standard interfaces: LAN, USB Host/Device, analog remote control terminal
• Optional interfaces: GPIB-USB adapter, RS232-USB cable
• LabVIEW driver and PC software support

Applications

• LED I-V characteristic curve measurement and verification
• Battery charging and discharging characterization
• Power electronics and converter testing
• Inrush current protection during device initialization
• Manufacturing and quality assurance testing
