GW Instek PSW-1080L445 DC Power Supply
Request a quote
GW Instek PSW-1080L445 is a triple-channel programmable switching DC power supply with 1080W maximum output, selectable 80V/80V/160V modules, and CV/CC priority protection.
Product details
| Model | PSW-1080L445 |
| Manufacturer | GW Instek |
| Category | DC Power Supplies |
| Availability | Made to order |
Description
Overview
The GW Instek PSW-1080L445 is a triple-channel programmable switching DC power supply delivering up to 1080W of output power. It features voltage modules selectable from 80V, 80V, and 160V per channel and is designed for precise power delivery with protection of sensitive devices.
Key Features
- Triple-channel output with maximum 1080W power; inter-channel latency less than 0.1ms
- Selectable voltage modules: 80V, 80V, and 160V per channel
- CV/CC priority mode selection for device-under-test (DUT) protection against inrush currents
- Adjustable slew rate for controlled voltage and current rise/fall times
- Over-voltage protection (OVP) and over-current protection (OCP) with 110% default threshold
- Advanced web server with SCPI command execution
- Standard interfaces: USB (Host/Device), LAN, and external analog remote control
- Optional interfaces: GPIB-USB adapter, RS232-USB cable
- LabVIEW driver and data logging software support
Applications
- LED I-V curve verification and characterization
- Battery charging and testing
- Power supply testing and validation
- Device manufacturing and validation tests
- Capacitive load and high-current device protection
Specifications
| Number of Outputs | Triple Output |
| Output Voltage | 80V x 2, 160V |
| Output Current | 13.5A x 2, 7.2A |
| Power Rating | 1080 W |
| Input Voltage | 85-265 VAC |
| Interface | USB, LAN |
| Display | LED |
| Series | PSW-Multi Series |
| Standards | CE Compliant |
| Warranty | 2 Years |
