GW Instek PSW-1080L222 DC Power Supply

Overview

The GW Instek PSW-1080L222 is a triple-channel programmable switching DC power supply delivering up to 1080W of output power. The PSW-Multi Series features multiple voltage module options and is designed for applications requiring precise control of device power and protection against inrush currents, particularly in LED testing and battery characterization.

The supply incorporates CV/CC (constant voltage/constant current) priority mode selection, allowing operation to begin in constant current mode during power-on to prevent current spikes that could damage sensitive loads. An adjustable slew rate feature enables controlled transitions in voltage and current, further protecting devices during power-on and power-off cycles.

Key Features

• Triple-channel output with 1080W maximum power
• Multiple voltage module options: 30V, 40V, 80V, 160V, 250V, and 800V
• CV/CC priority mode selection for device protection
• Adjustable slew rate for controlled voltage and current transitions
• Overvoltage protection (OVP) and overcurrent protection (OCP) with configurable thresholds
• Advanced web server interface supporting SCPI command execution
• Multiple communication interfaces: USB, LAN, and external analog remote control
• Optional GPIB-USB and RS232-USB communication adapters
• LabVIEW driver and Data Logging software support
• Bleed circuit for accelerated voltage fall time
• Sequence storage capability via USB for automated test execution

Applications

• LED testing and characterization including I-V curve measurement
• Battery charging and discharge cycle testing
• Large capacitor testing and charge/discharge sequences
• Manufacturing test equipment for lighting devices
• Power supply development and validation
• Laboratory and research applications requiring precise multi-channel power control
