GW Instek PSW-1080L124 DC Power Supply

Overview

The GW Instek PSW-1080L124 is a programmable switching DC power supply featuring three independently programmable channels capable of delivering 1080W total output power. The unit provides voltage modules of 30V, 40V, and 80V, with an advanced web server interface for SCPI command execution and remote control capabilities. This power supply is designed for LED, battery, and other applications requiring precise DC power delivery with protection against inrush currents.

Key Features

• Triple-channel output with 1080W maximum power capacity
• Voltage configuration: 30V/40V/80V channels
• CV/CC priority mode selection for DUT protection against inrush currents
• Adjustable slew rate for controlled voltage and current transitions
• Over-voltage (OVP) and over-current (OCP) protection at 110% of rated values
• Advanced web server with SCPI command execution and data logging
• Standard LAN and USB interfaces; optional GPIB and RS232 adapters
• LabVIEW driver and data logging software support
• Analog remote control terminal for external On/Off control and monitoring

Applications

• LED I-V curve characterization and testing
• Battery charging and discharge testing
• Component and device burn-in testing
• Power conditioning for capacitive and inductive loads
• Automated test sequence execution via USB flash drive
