GW Instek PSW-1080L112 DC Power Supply
Request a quote
GW Instek PSW-1080L112 triple-channel DC power supply with 1080W output, mixed voltage channels (30V, 30V, 40V), CV/CC priority mode, and web-based control.
Product details
| Model | PSW-1080L112 |
| Manufacturer | GW Instek |
| Category | DC Power Supplies |
| Availability | Made to order |
Description
Overview
The GW Instek PSW-1080L112 is a triple-channel programmable switching DC power supply designed for flexible testing and production applications. With a maximum output of 1080W and mixed-voltage channels (30V, 30V, 40V), it accommodates diverse power requirements in a single unit. The supply features intelligent CV/CC priority mode selection and advanced web-based control through SCPI commands.
Key Features
- Triple-channel configuration with 1080W maximum output
- Mixed voltage channels: two 30V and one 40V for flexible testing
- CV/CC priority mode selection for Device Under Test (DUT) protection
- Adjustable slew rate control for voltage and current transitions
- Advanced web server with SCPI command execution and data logging
- Over-Voltage Protection (OVP) and Over-Current Protection (OCP) at 110% of rated values
- Standard interfaces: LAN, USB, analog control terminal
- Optional: GPIB-USB adapter, RS232-USB cable
- LabVIEW driver support
Applications
- Multi-voltage device testing requiring different supply voltages
- LED testing and characterization
- Battery testing and cycling
- Manufacturing test environments with mixed-voltage requirements
Specifications
| Number of Outputs | Triple Output |
| Output Voltage | 30V x 2, 40V |
| Output Current | 27A, 36A x 2 |
| Power Rating | 1080 W |
| Input Voltage | 85-265 VAC |
| Interface | USB, LAN |
| Display | LED |
| Series | PSW-Multi Series |
| Standards | CE Compliant |
| Warranty | 2 Years |
