GW Instek PSW-1080H888 DC Power Supply
Request a quote
GW Instek PSW-1080H888 triple-channel DC power supply with 1080W output, all channels at 800V, CV/CC priority protection, and advanced web-based control.
Product details
| Model | PSW-1080H888 |
| Manufacturer | GW Instek |
| Category | DC Power Supplies |
| Availability | Made to order |
Description
Overview
The GW Instek PSW-1080H888 is a triple-channel programmable switching DC power supply designed for advanced testing and production environments. With a maximum output of 1080W and all three channels configured at 800V, it delivers high-voltage power distribution for demanding device testing requirements. The supply features intelligent CV/CC priority mode selection and advanced web-based control through SCPI commands.
Key Features
- Triple-channel configuration with 1080W maximum output
- All channels at 800V for high-voltage applications
- CV/CC priority mode selection for Device Under Test (DUT) protection
- Adjustable slew rate control for voltage and current transitions
- Advanced web server with SCPI command execution and data logging
- Over-Voltage Protection (OVP) and Over-Current Protection (OCP) at 110% of rated values
- Standard interfaces: LAN, USB, analog control terminal
- Optional: GPIB-USB adapter, RS232-USB cable
- LabVIEW driver support
Applications
- High-voltage power distribution testing
- LED I-V curve verification and testing
- Battery charging and discharge characterization
- Industrial device testing requiring high-voltage supplies
Specifications
| Number of Outputs | Triple Output |
| Output Voltage | 800V x 3 |
| Output Current | 1.4A x 3 |
| Power Rating | 1080 W |
| Input Voltage | 85-265 VAC |
| Interface | USB, LAN |
| Display | LED |
| Series | PSW-Multi Series |
| Standards | CE Compliant |
| Warranty | 2 Years |
