GW Instek PSW-1080H668 DC Power Supply
Request a quote
GW Instek PSW-1080H668 is a programmable 3-channel DC power supply with 1080W output supporting 250V/250V/800V configuration with CV/CC priority mode.
Product details
| Model | PSW-1080H668 |
| Manufacturer | GW Instek |
| Category | DC Power Supplies |
| Availability | Made to order |
Description
Overview
The GW Instek PSW-1080H668 is a programmable switching DC power supply from the PSW-Multi series, featuring three independent channels with 1080W maximum output power. It is designed for a wide range of testing applications requiring flexible voltage and current control with built-in protection mechanisms.
Key Features
- Three independent channels with 250V/250V/800V configuration
- 1080W maximum output power
- Programmable voltage and current settings
- CV/CC priority mode selection for DUT protection
- Adjustable slew rate for controlled voltage/current transitions
- Over-voltage protection (OVP) and over-current protection (OCP)
- Advanced web server for SCPI command execution
- Standard interfaces: USB, LAN, external analog control
- Optional: GPIB-USB adapter, RS232-USB cable
- LabVIEW driver and data logging software support
Applications
- Battery and LED testing and characterization
- Component and circuit board testing
- High-voltage circuit testing and verification
- Research and development of power-consuming equipment
Specifications
| Number of Outputs | Triple Output |
| Output Voltage | 250V x 2, 800V |
| Output Current | 1.4A, 4.5A x 2 |
| Power Rating | 1080 W |
| Input Voltage | 85-265 VAC |
| Interface | USB, LAN |
| Display | LED |
| Series | PSW-Multi Series |
| Standards | CE Compliant |
| Warranty | 2 Years |
