GW Instek PSU 150-10 High-Voltage DC Power Supply

Overview

The GW Instek PSU 150-10 is a programmable high-voltage DC power supply with 150V/10A output and 1500W power rating. Designed for high-voltage applications and test system integration, the PSU 150-10 features high power density in a compact 1U form factor. It is suitable for DC/DC converter testing, servomotor applications, capacitor aging tests, and semiconductor production equipment.

Key Features

• Output: 150V, 10A, 1500W
• CV/CC Priority mode with adjustable voltage/current rise and fall time
• 1U height, 19-inch rack mount compatible
• Series/parallel connection capability (max 2 units under 300V, max 4 units parallel)
• Standard interfaces: USB, LAN, RS-232, RS-485, Analog Control
• Optional interfaces: GPIB, Isolated Analog Interface (Voltage/Current Control)
• Trigger input/output control with 1-60ms pulse width
• Protection: OVP, OCP, OHP, UVL, AC Fail, FAN Fail
• 2-year warranty

Applications

• DC/DC converter primary input and testing
• Servomotor and motor control testing
• Capacitor aging and reliability testing
• Diode and semiconductor device testing
• High-voltage component burn-in and production testing
• Automotive electronics and ECU testing

Included Accessories

• User Manual + Programming User Manual (CD)
• Output Terminal Cover
• Analog Connector Plug Kit
• Input Terminal Cover
• 1U Handle (RoHS)
• 1U Bracket (Left, RoHS)
• 1U Bracket (Right, RoHS)
