HT Instruments I-V500w Curve Tracer
Request a quote
HT Instruments I-V500w is a solar PV curve tracer measuring I-V characteristics up to 1500V/10A, with internal memory for 249 curves, WiFi connectivity, and backlit LCD.
Product details
| Model | I-V500w |
| Manufacturer | HT Instruments |
| Category | Circuit Testers & Tracers |
| Availability | Made to order |
Description
Overview
The HT Instruments I-V500w is a high-performance curve tracer designed for the analysis and testing of photovoltaic (PV) modules and strings. Capable of tracing I-V curves up to 1500V/10A or 1000V/15A, it is ideal for commissioning, diagnostics, and maintenance of modern PV systems. The instrument includes internal memory, wireless connectivity, and a backlit display for accurate, efficient field testing.
Key Features
- I-V curve tracing on individual PV modules or complete strings up to 1500V/10A or 1000V/15A
- Measures open-circuit voltage (Voc) and short-circuit current (Isc)
- Internal memory for storing up to 249 I-V curves
- Custom PV module database: 30 modules internally, 30,000 via software or app
- Compatible with remote unit SOLAR-02 for wireless measurement of irradiance and temperature
- Measures cell and ambient temperature and direct irradiation using a reference cell
- Backlit LCD display for enhanced visibility in all lighting conditions
- Integrated Wi-Fi connectivity with HTAnalysis App for Android/iOS
- PC interface with included Windows software for data management and analysis
- Auto power-off function to preserve battery life
- CAT III protection standards for safety in field applications
Applications
- Commissioning and testing of photovoltaic systems
- Diagnostics and maintenance of PV modules and strings
- Quality control and performance analysis of solar installations
Specifications
| Backlight | Yes |
| Battery Life | 1.5 hrs. |
| Battery Type | 6x1.5V alkaline batteries type AA, LR06 |
| Display | LCD |
| Frequency Range | 2.462 GHz |
| Height | 75 mm |
| Includes | Calibration report User manual and quick guide Reference Cell Hard Case Set Of Adapters Banana Set Of Cables And Alligator Clips Optical/USB cable C2006 and downloadable TopView software |
| Length | 235 mm |
| Operating Temperature | 0 to 40°C |
| Product Type | Curve Tracers |
| Storage Temperature | -10 To 60°C |
| Width | 165 mm |
