Fluke FLUKE-709H Current Loop Calibrator

Overview

The Fluke 709H is an advanced current loop calibrator that combines precise measurement and sourcing of 4-20 mA signals with powerful HART communication and data management features. Designed for technicians who service HART-enabled process transmitters and control valves, it provides diagnostic capabilities previously available only in dedicated HART communicators or high-end multi-function calibrators.

Key Features

• 0.01% reading accuracy for measurement and source modes
• Built-in HART modem with 250 Ω resistor for comprehensive HART communication
• Fast transfer of calibration data via 709H/TRACK software
• Data logging for recording transmitter information and troubleshooting
• 24 V DC loop power with mA measurement range of -25% to 125%
• 1 µA resolution on mA ranges and 1 mV on voltage ranges
• Quick-Set rotary encoder for fast setup and intuitive operation
• HART device configuration storage and management for up to 20 devices
• Valve test function with Good, Marginal, or Bad assessment
• Battery-powered with six AAA batteries and auto-shutdown feature
• Three-year warranty

Applications

• HART transmitter setup, diagnostics, and field troubleshooting
• Calibration and maintenance of 4-20 mA control loops
• Control valve testing and performance assessment
• Documentation of HART device configurations for compliance and maintenance records

Included Accessories

• Extended tooth alligator clip set
• 75X-8014 stackable lead set
• TP220 Test Probes
• AC280 SureGrip Hook Clips
• HART cable
• Soft carrying case
• Six AAA batteries (installed)
• Product manual on CD-ROM
• Quick reference guide
• Safety information guide
• NIST traceable calibration certificate with data
