Fluke 9142-E-156 Dry-Well Field Calibrator

Overview

The Fluke 9142-E-156 is a portable field metrology well with integrated temperature readout for professional calibration work. Designed for rapid temperature ramp rates while maintaining metrology-grade stability and uniformity, it provides -25°C to 150°C coverage in a compact, field-portable package. The unit comes equipped with Insert E for metric probe hole sizes, making it immediately ready for use in field calibration applications.

Key Features

• Temperature range: -25°C to 150°C
• Accuracy: ± 0.2°C (full range)
• Stability: ± 0.01°C (full range)
• Radial uniformity: ± 0.01°C (full range)
• Axial uniformity at 40 mm (1.6 in): ± 0.05°C
• Immersion depth: 150 mm (6 in)
• Built-in two-channel readout for PRT, RTD, thermocouple, and 4-20 mA current
• Large LCD display visible in low-light environments
• Visual and audible stability indicator
• Pre-programmed calibration routines
• Onboard non-volatile memory for documentation of up to 20 tests
• RS-232 interface with 9930 Interface-it control software
• NIST-traceable IEC-17025 NVLAP-accredited calibration certificate
• Includes Insert E with metric holes: 3 mm, 4 mm, 6 mm, 8 mm, 10 mm and 0.25-inch reference

Applications

• Loop calibration of temperature transmitters
• Thermocouple calibration or verification
• RTD or PRT calibrations
• Testing of thermostatic switches
• Verification of industrial thermometers

Included Accessories

• Insert E (Metric Misc) with metric holes: 3 mm, 4 mm, 6 mm, 8 mm, 10 mm and 0.25-inch reference hole
• NVLAP and NIST-traceable calibration certificate
• Power cord
• 9930 Interface-it software (RS-232)
• User manual
