Fluke 9142-DW-156 Dry-Well Field Calibrator

Overview

The Fluke 9142-DW-156 is a lightweight, portable field metrology well calibrator without included inserts for temperature measurement and sensor calibration. It maintains the 9140 Series standards for accuracy, stability, uniformity, loading, and hysteresis. This model is ideal for users who already have compatible inserts or prefer to select specific probe hole configurations separately.

The 9142-DW-156 features two-channel readout capability for PRTs, RTDs, and thermocouples. The model accommodates various probe sizes through optional multiple-hole inserts available separately, supporting all standard insert configurations.

Key Features

• Temperature range: -25°C to 150°C (at 23°C ambient)
• Accuracy: ±0.2°C (full range)
• Stability: ±0.01°C (full range)
• Radial uniformity: ±0.01°C (full range)
• Axial uniformity: ±0.05°C at 40 mm immersion depth
• Immersion depth: 150 mm (6 inches)
• Large LCD display with easy-to-navigate menus and function keys
• Visual and audible stability indicator for calibration readiness
• Pre-programmed calibration routines in onboard non-volatile memory (up to 20 tests)
• One-button temperature setpoint control
• Reference readout accepts plug-and-play smart connector
• Two-channel readout for PRT, RTD, and thermocouple
• No inserts included; compatible with all standard insert types (A through Z)
• IEC-17025 NVLAP-accredited calibration certificate with uncertainty analysis

Applications

• Loop calibration of temperature transmitters
• Thermocouple calibration and verification
• RTD and PRT calibration
• Testing of thermostatic switches
• Verification of industrial thermometers

Included Accessories

• 9142-DW-156 Metrology Well without insert
• Power cord
• 9930 Interface-it software
• NVLAP NIST-traceable calibration certificate
• User's manual
