Keysight M8195A Arbitrary Waveform Generator
Request a quote
Keysight M8195A is a high-speed arbitrary waveform generator with 65 GSa/s sample rate, 25 GHz bandwidth, and up to 4 channels in a single AXIe module.
Product details
| Model | M8195A |
| Manufacturer | Keysight |
| Category | Bit Error Rate Testing |
| Availability | Made to order |
Description
Overview
The Keysight M8195A is a high-speed arbitrary waveform generator providing up to 65 GSa/s sample rate with 25 GHz bandwidth and 8-bit vertical resolution. It supports up to 4 channels in a single 1-slot AXIe module, enabling complex signal generation for digital applications, optical communications, wideband radar, and research applications.
Key Features
- Sample rate up to 65 GSa/s with 25 GHz analog bandwidth
- High channel density: 1, 2, or 4 channels per module
- 2 GSa of waveform memory per module, expandable to 16 GSa
- Up to 1 Vpp(se) or 2 Vpp(diff) output amplitude
- Advanced 3-level sequencing for complex signal scenarios
- Built-in frequency and phase response calibration
- Synchronization of up to 16 channels across 4 modules with M8197A
- Trigger delay accuracy of ±20 ps (with M8197A synchronization module)
- 32 GBaud signal capability and beyond
- Real-time waveform and impairment generation with embedded DSP
Applications
- Coherent optical communications with dual polarization I/Q baseband signals
- Multi-level digital signals (NRZ, PAM4, PAM8, DMT) up to 32 GBaud
- High-speed protocol generation (HDMI, C-PHY, D-PHY)
- Wideband RF/microwave signal generation from DC to 25 GHz
- Physics, chemistry, and electronics research
- Aerospace and defense communication applications
Specifications
| Channel/Port Count | 2 |
| Channel/Port Count | 4 |
| Maximum Sample/Data Rate | 65 GS/s |
