Keysight M8190A Arbitrary Waveform Generator
Request a quote
Keysight M8190A delivers high-fidelity arbitrary waveform generation with 14-bit resolution at 8 GSa/s or 12-bit at 12 GSa/s, 5 GHz analog bandwidth, and up to 90 dBc SFDR for advanced signal testing.
Product details
| Model | M8190A |
| Manufacturer | Keysight |
| Category | Bit Error Rate Testing |
| Availability | Made to order |
Description
Overview
The Keysight M8190A is a high-fidelity arbitrary waveform generator delivering precision signal generation with selectable resolution and sample rate settings. With 14-bit resolution at up to 8 GSa/s or 12-bit resolution at up to 12 GSa/s, combined with 5 GHz analog bandwidth and up to 90 dBc spurious-free dynamic range (SFDR), the M8190A enables R&D and test engineers to create realistic signal scenarios for advanced testing applications.
Key Features
- 14-bit resolution up to 8 GSa/s or 12-bit resolution up to 12 GSa/s
- Variable sample rate from 125 MSa/s to 8 GSa/s or 12 GSa/s
- Spurious-free dynamic range (SFDR) up to 90 dBc typical
- Up to 2 GSa arbitrary waveform memory per channel
- 5 GHz analog bandwidth for custom inter-symbol interference generation
- Advanced sequencing capabilities
- Compatible with MATLAB, BenchLink Waveform Builder Pro, and Wideband Waveform Center software
Applications
- Radar and electronic warfare signal generation
- Analog-to-digital converter (ADC) testing
- Jitter margin testing and characterization
- Multilevel signal generation for advanced modulation formats
- OFDM and wireless HD (802.11ad) signal creation
- HDMI and MHL interface testing
- Software-defined radio (SDR) and satellite communication applications
- Noise power ratio measurement
Specifications
| Channel/Port Count | 2 |
