GW Instek ASR-2050R Programmable AC/DC Power Source
Request a quote
GW Instek ASR-2050R 500VA AC/DC power source in 3U 1/2 rack mount format; 350V AC, 500V DC with programmable modes and comprehensive protection.
Product details
| Model | ASR-2050R |
| Manufacturer | GW Instek |
| Category | AC Power Sources |
| Availability | Made to order |
Description
Overview
The GW Instek ASR-2050R is a compact 500VA programmable AC/DC power source designed for rack-mount applications. It delivers both AC (0–350 Vrms) and DC (0–±500 V) outputs and is optimized for 3U height and 1/2 rack width configuration, making it ideal for system integration with automatic test systems.
Key Features
- 500VA power rating with 5A AC and 2.5A DC maximum output current
- 3U height, 1/2 rack width design for ATS compatibility
- Output range: AC 0–350 Vrms; DC 0–±500 V
- Nine operation modes: AC, DC, AC+DC, and external signal modes
- Frequency output up to 999.9 Hz
- Measurement: Vrms, Vavg, Vpeak, Irms, Iavg, Ipeak, P, S, Q, PF, CF, THDv, THDi
- Waveform generation: Sequence, Arbitrary, and Simulate modes
- Remote sensing and customized phase angle control
- Protection: OVP, OCP, OPP, OTP, AC Fail Detection, Fan Fail Alarm
- Memory storage for up to 10 configurations
Applications
- Automatic test systems and production testing
- Rack-mounted laboratory setups
- Electronic component qualification
- Automotive and appliance power testing
Specifications
| Series | ASR-2000 Series |
