Chroma 61603 Programmable AC Power Source
Request a quote
Chroma 61603 1.5 kVA programmable AC power source with 0–300V output, 15–1000 Hz frequency range, and integrated measurement capabilities for electrical testing.
Product details
| Model | 61603 |
| Manufacturer | Chroma |
| Category | AC Power Sources |
| Availability | Made to order |
Description
Overview
The Chroma 61603 is a single-phase programmable AC power source delivering pure, instrument-grade AC power at very low cost. It features output voltage from 0 to 300V and frequency from 15 to 1000 Hz, making it suitable for commercial, avionics, military, and general testing applications from bench-top design verification to mass production.
Key Features
- AC, DC, and AC+DC output modes
- Delivers full power with up to 6:1 crest factor loads
- Analog signal input for high-power amplifier operation
- Programmable voltage, current limit, and frequency with selectable slew rates
- Turn on/off phase angle control for inrush current testing
- 16-bit precision measurement of Vrms, Irms, Ipk, true power, inrush current, frequency, crest factor, power factor, VA, and VAR
- Input power factor correction
- Nine programmable voltage and frequency recall settings
- GPIB, RS-232C, and Analog Programming Interface Board included
Applications
- Power input range testing for products in variable AC line conditions
- Inrush current testing with programmable phase angle control
- Transient power simulation for switching-mode power circuit testing
- Commercial, avionics, and military equipment testing
- Bench-top research and development
- Mass production quality assurance
Specifications
| Power Rating | 1.5 kVA |
| Series | 61600 Series |
| Type | AC |
